Paddy peeling machine is used to separate the paddy from the shell. Paddy is separated from its shell by passing it through two cylinders that are opposite to each other and rotating at different speeds. Shell, paddy and brown rice are divided into 3 as immature grains.
Control system that automatically adjusts the gap between the rubber rollers to ensure the most efficient peeling process
Sensor that closes the feed chute in case of running out of paddy
Feed chute with inspection window
Steel body
V belt transmission
PLC automatic control
Technical Specifications
Machine No / Machine No: INO-PDH
Machine Name / Machine Name: Paddy Peeler – Paddy Husker
Dimensions / Dimensions: A 1579 mm – B 1910 mm – C 1808 mm
Motor Power Motor Power: 11 kW +4 kW – 1400 rpm
Weight Weight: 1124 kg
Capacity Capacity: 3,5 tons / hour
